The operation of the Biolan Greywater Filter light is based on the mechanical and biological filtration of grey water. The organic filter material used in the filter, attracts the phosphates and impurities in the wastewater. The micro-organisms living on the surface of the filter material use the impurities in the water as their nutrition.
The module has five filter boxes layered one on top of the other. The wastewater enters into the uppermost filter box. Inside the module, the wastewater flows by gravity from one filter layer to the other through the openings in the end each box. Finally the clean water exists the module and out to a gravel leach bed.
Human waste, storm water or drainage water from foundations must not be fed into the filter. The cleaning capacity of the filter material in the module is good for about 3-6 months depending on volume, after which it needs to be replaced in accordance with the maintenance instructions. The Biolan grey water filter tolerates a small amount of anti-bacterial and chlorine-based agents that are commonly used for cleaning. However, toxic chemicals or substances that contain chemicals that can kill the micro-organisms that clean the wastewater, such as drain openers, paints, oils or solvents, must not be fed into the purifier.
| A properly dimensioned, installed and operated Biolan Greywater Filter light wastewater system meets the limit values for total phosphorus, total nitrogen and organic material in grey wastewater in accordance with the Environmental Protection law (527/2014) and the Decree (157/2017). |
Dimensions
- dimensions of the module (width x height x depth): 56 x 58 x 96 cm
- two modules installed in parallel (width): about 1.30 m
- two modules installed in parallel (depth): min. approximately 2.03 m
- pipe connectors: for Ø 75 mm sewer pipes (2 x 75mm to 3" PVC adapters provided)
- height difference of inlet and outlet connectors: 45 cm (height of fall)
- capacity: 300 litres/day/module
- weight without the filter material: 24 kg
- the distance, travelled by water in the filter material: 325 cm/module
